Enterprise-class Android
Every TC55 ships with Mobility Extensions (Mx), a series of features that transform AndroidTMfrom a consumer operating system (OS) to a true enterprise-class OS, providing enterprise-class security and device management, as well as enterprise data capture capabilities.

Mobility DNA
Every strand of your mobility platform is simpler with Zebra’s Mobility DNA. That’s because, from the start, you have the industry’s most comprehensive suite of mobility must-haves to accelerate your solution. You get more off-the shelf end-user apps, more robust administration utilities and easier app development. Purpose-built for enterprise, Mobility DNA makes ease, confidence and value intrinsic to your investment and our full line of Android mobile computers.

Advanced capacitive touch screen that works virtually anywhere
The 4.3 in. high-resolution display isn’t just bigger, it’s significantly better. Based on cutting-edge HAST LCD technology, the screen is brighter both indoors and outdoors, all while consuming substantially less energy. Furthermore, the capacitive touch panel dynamically adjusts to the current environment, enabling it to work with or without gloves, wet or dry and with your finger or a stylus.

Superior audio quality and functionality for a new level of voice flexibility
Up to four times the loudness of popular smartphones, the TC55’s noise cancelling technology provides crystal clear audio on both ends of every call. Support for Workforce Connect Push-to-Talk (PTT) Pro provides an instant connection to co-workers in the field, plus supervisors and other support staff back in the office.

Integrated scanner and imager for fast, accurate data capture
Increase productivity with the integrated 1-D and 2-D scanners, an optional 1-D/2-D ring-style Bluetooth scanner, an 8 MP camera and Near Field Communications (NFC), so workers can quickly and easily capture virtually any type of data at the press of a button.

Automatically capture data on an entire form with SimulScan
With SimulScan Document Capture, your workers can capture bar codes, text fields, phone numbers, images and even check boxes in the time it takes to press a button, improving invoicing speed, order speed, cash flow and more.

Standard or professional configuration to meet your needs
Both built on Android Open Source (AOSP), the Standard Configuration comes with Google Mobile Services (GMS), a suite of integrated Google applications standard on most smart phones - ideal for workers that depend on apps such as Gmail or Google Maps. Our Professional Configuration ships without GMS, promoting greater privacy and security of personal information by preventing location tracking and data collection — providing a solution for businesses with strict security policies.

WPAN (Bluetooth Support)
Bluetooth 4.0
WWAN radio type
3.75 LTE, HSPA+, EDGE/GPRS/GSM
Frequency band
EDGE/GPRS/GSM: 850/900/1800/1900 MHz
HSPA+ Americas: 850/1900/1700-2100 + 900/ 2100 MHz
HSPA+ Rest of the World: 900/2100 + 850/1900 MHz
LTE Americas: FDD2, FDD4, FDD5, FDD17
Integrated GPS
Integrated, Autonomous, Assisted-GPS (A-GPS), GLONASS
WLAN radio type
Tri-mode IEEE® 802.11a/b/g/n
Individual data rates supported
802.11a - up to 150 Mbps; 802.11b/g - up to 72.2 Mbps; 802.11n @ 2.4 GHz up to 72 Mbps; 802.11n @ 5 GHz up to 150 Mbps
Security
WEP (40 or 104 bit) ; WPA/WPA2 Personal; WPA/WPA2 Enterprise — EAP-TTLS (PAP, MSCHAP, MSCHAPv2),
EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, TKIP, AES

Operating system (OS)
Android 4.1.2
Data capture options
Bar Code Scanning: Integrated 1D* linear imager; optional RS507 Bluetooth ring-style imager
Camera: Autofocus 8 MP with user-controllable flash; supports integrated 1D/2D bar code capture
Camera/Imager Exit Windows: Corning Gorilla Glass 2
NFC: Peer-to-peer, card reader, card emulation
Memory (Flash/RAM)
1 GB RAM / 8 GB Flash
Processor (CPU)
1.5 GHz dual core processor
Interfaces
USB 2.0 High Speed (host and client), WLAN, WWAN and Bluetooth

Expansion slot
User accessible 32GB microSD slot with SD HC support
Voice and Audio
Two front-facing speakers; dual noise-cancelling microphones; high-quality speaker phone; 3.5mm headset jack; Bluetooth wireless headset support
Notification
Vibrate and audible tone
Touch panel
Dual mode capacitive touch with stylus or fingertip (bare or gloved) input
Keypad options
On-screen keypad
Display type
Blanview® LCD display, 4.3 in. WVGA , exceptional low power consumption, exceptionally bright image with 700 NITs, 3% transflective, Corning Gorilla Glass 2
Weight
With standard battery: 7.8 oz./220 g
Dimensions (HxWxD)
With standard battery:
5.4 in. L x 2.7 in. W x 0.63 in. D / 137 mm L x 69 mm W x 15.9 mm D
LED Safety
EN 62471
WWAN
Global: 3GPP TS 51.010, 3GPP TS 34.121, 3GPP TS36.521, 3GPP TS 34.123, 3GPP TS36.523, GCF and PTCRB approved
USA: FCC Part 22, Part 24
Canada: RSS-132, RSS-133, 139
EU: EN301 511, EN301 908
Australia: AS/ACIF S042.1, 3 & 4
WLAN
USA: FCC Part 15.247, 15.407, 15.225
Canada: RSS-210
EU: EN 300 328, EN 301 893, EN 302 291
Australia: AS/NZS 4268
Bluetooth/NFC
USA: FCC Part 15.247, 15.407, 15.225
Canada: RSS-210
EU: EN 300 328, EN 301 893, EN 302 291
Australia: AS/NZS 4268
RF exposure
US: FCC Part 2, FCC OET Bulletin 65c; Canada: RSS 102 Issue 4; EU: EN 50360; EN 50566; EN 62479; EN 62311; Australia: Radiocommunications Standard 2003
Environmental
RoHS/WEEE compliant, EN 50581
Electrical safety
UL 60950-1, EN 60950-1, IEC 60950-1
EMI/RFI
USA: FCC Part 15, Class B
Canada: ICES-003 Class B
EU: EN55022 Class B, EN 55024, EN 301 489-1, EN 301 489-3, EN 301 489-7, EN 301 489-17, EN 301 489-24, EN 60601-1-2, EN 50121-3-2, EN 50121-4
Australia: AS/NZS CISPR 22
Environmental sealing
IP67, meets IEC specifications
Motorola Interactive Sensor Technology (IST)
Ambient Light Sensor: Automatically adjusts display backlight to maximize power efficiency
Proximity Sensor:Automatically detects when the user places the handset against head during a phone call to disable display output and touch input
Thermal shock
-40°F to 158°F/-40°C to 70°C rapid transition
Shock/Vibration
Vibration: MIL-STD 810G, 2Gs peak, 5Hz to 2kHz, 1 hour per axis; .04gˆ2/Hz, 20Hz to 2kHz, 1 hour per axis
Humidity
5% to 85% non-condensing
Drop specification
4 ft./1.2 m drop to plywood per MIL-STD 810G; With protective boot: 4 ft./1.2 m to concrete across the operating temperature range
Storage temperature
-40°F to 158°F/-40°C to 70°C
Operating temperature
14°F to 122°F/-10°C to 50°C
